Alimac at Drinktec 2025

Written by admin on April 17, 2025. Posted in News.

Drinktec 2025 is the leading global trade fair for the beverage and liquid food industry, bringing together companies from around the world to showcase innovations in technology, ingredients, and packaging solutions.

Key focus areas:

Sustainability and circular economy in production
Data and digitalization for efficiency
Health and lifestyle trends shaping consumer demand
Live machinery demonstrations of cutting-edge solutions

Drinktec offers an opportunity to explore industry developments, connect with experts, and expand business potential.

Alimac Group will participate in the fair at HALL C2, BOOTH 145.

Do you want to attend? Fill out the following form to obtain a free voucher!

PP102

Written by admin on April 11, 2025. Posted in Products.

Foam

The PP102 tape is used to cover the middle part of adhesive carry handles. It is strong, lightweight, and environmentally friendly because it is made of polypropylene (PP). You can also customize it with different colors or prints based on your needs.

Specifications

Material:	Special PP foam
Thickness:	120 µm (very thin)
Density:	Light (63 g/m²)
Strength:	Very strong (100 N/mm²)
Stretch:	Flexible (25%)
Color:	White or printed as requested
Shelf life:	12 months

Available sizes

Big Rolls (6″ core):	25 mm x 3500 m 37.5 mm x 2500 m Packed: 1 roll per box, 48 boxes per pallet
Small Rolls (3″ core):	25 mm x 660 m 37.5 mm x 660 m Packed: 10 rolls per box (42 boxes per pallet) or 6 rolls per box (42 boxes per pallet)

Other sizes available upon request

Pallet dimensions

Dimensions: 80 x 120 x 170 cm

Weight: 470 to 720 kg

PP102 Leaflet

Note: The above-mentioned data is based on long-term experience but cannot represent a warranty against eventual damage. Tests should be performed prior to any application.

How the PP102 can serve your needs and provide you value

Strong
Lightweight
Eco-friendly

Discover all the products available in our catalog.

Our catalog

Let’s grow together – “Plastica Seconda Vita” certification!

Written by admin on April 4, 2025. Posted in News.

We are happy to share great news: the C705 HL product has received the “Plastica Seconda Vita” certification!

This important recognition confirms Alimac’s strong commitment to using post-consumer recycled polyethylene in our production process. The “Plastica Seconda Vita” certification is a key standard that identifies and promotes products made with recycled materials. For Alimac, this is another step toward more sustainable and environmentally friendly solutions.

This achievement is the result of the collective effort of all our employees. Every contribution, big or small, has helped us reach this goal. Step by step, we can make a difference for a greener future.

Let’s continue to innovate and work to make our actions a positive force for the planet!

C705 HL LDPE70

Written by admin on March 13, 2025. Posted in Products, Recommended products.

Pre-laminated

The adhesive tape C705 HL LDPE70 consists of a transparent MOPE tape laminated with LDPE insert. The handle is suitable to be recycled together with the shrinkable PE of the bottle pack.

Specifications

Backing Type:	MOPE
Thickness:	55 μm
Total thickness:	75 μm
Adhesion on steel:	10 N/25 mm
Adhesion on PE:	5.0 N/25 mm
Tensile strength:	300 N/25 mm
Elongation:	40%
Color:	Transparent
Insert:	PE 70 μm white
Printing:	Up to 6 colours

Storage

Temperature: 10°C to 40°C

Humidity: 20% to 80% RH

Shelf life: 12 months
Available sizes

25 mm x 3500 m (with 6″ H 180 core): 1 roll/box, 48 boxes/pallet (about 370 kg)

25 mm x 5000 m (with 6″ H 350 core): 1 roll/box, 24 boxes/pallet (about 500 kg)

Other sizes available upon request

C705 HL LDPE70 Leaflet

C705 HL LDPE70 TDS

Note: The data provided are reference values based on long experience in the manufacture of handles and do not constitute a guarantee for the results of the application. Every single application should be tested in advance. We decline any responsibility for direct or indirect damage due to the application of the handle on materials other than shrink PE film.

How the C705 HL LDPE70 can serve your needs and provide you value

Sustainability and Environment
Convenience and Comfort
Customization and Versatility

Discover all the products available in our catalog.

Our catalog

C105 FA – UV

Written by admin on February 24, 2025. Posted in Products, Recommended products.

Traditional

The C105 FA UV tape exhibits technical characteristics suitable for preparing adhesive handles for heavy packages when high adhesion is required. It is particularly resistant to UV rays.

Specifications

Backing type:	MOPP
Thickness:	50 μm
Total thickness:	80 μm
Adhesion on steel:	18 N/25 mm
Adhesion on PE:	11 N/25 mm
Tensile strength:	350 N/25 mm
Elongation:	30%
Color:	Transparent

Storage

Temperature: 10°C to 40°C

Humidity: 20% to 80% RH

Shelf life: 12 months
Available sizes

mm 25 X 5000-6000 m with 6″ core H 180: 1 roll/box

mm 30 X 5000 m with 6″ core H 180: 1 roll/box

48 boxes/pallet

Other sizes available upon request

C105 FA – UV Leaflet

C105 FA – UV TDS

Note: The data provided are reference values taken from production samples and do not constitute a guarantee for the results of the application. Every single application should be tested in advance.

How the C105 FA – UV can serve your needs and provide you value

Strong grip & Sunproof
Enduring performance
Customization and Versatility

Discover all the products available in our catalog.

Our catalog

TA25

Written by admin on February 23, 2025. Posted in Products.

Dispenser

The TA25 handle dispenser by ALIMAC is an essential tool for the efficient management of handles for package transport. Designed for handles up to 50 mm (2″) in width, with a maximum external diameter of 360 mm and 75 mm (3″) cores, this bench dispenser combines precision, robustness, and ease of use. Perfect for professional applications, the TA 25 ensures clean cuts and quick, effortless application.

Key features

Item: TA25

Usage: Bench dispenser for adhesive tapes

Width: Up to 50 mm (2″)

Maximum External Diameter: 360 mm

Core Size: 75 mm (3″)

Specifications

Blades:	Sharp movable and fixed blades for precise cutting
Core Holder Extension:	Fixable
Knurled Knob:	Adjustable braking torque to control tape unrolling
Measuring Arm:	Adjustable to the desired length and fixable with a knob
Material:	Made of durable materials for long-lasting use

Setting
1. Fix the core holder extension using the enclosed handwheels.
2. Secure the dispenser to the table with screws (not included) or pieces of double-sided tape.
3. Load the tape as shown in the provided photo.
4. Adjust the knurled knob to the minimum braking torque that avoids easy unrolling of the tape.
5. Set the measuring arm to the desired length and fix it with the knob.

Maintenance

Blade Cleaning:	Remove adhesive from the blades using a plastic or wooden tool and clean with alcohol.
Lubrication:	Periodically lubricate the shafts of the rolls using Vaseline oil. Do not use solvents.
2Spare Parts:	All spare parts are available to extend the product’s life. Contact your supplier to obtain parts. Particular care is required when replacing the blades.

Other sizes available upon request

Recycling

When disposing of the product, consider resource efficiency, waste handling, and cleanliness. Disassemble the product into metal and plastic parts and recycle separately. Plastic parts are mainly made of ABS and PA (polyamide) resins. Dispose of the product according to the waste management laws of the country where it is used.

TA25 Leaflet

Note: This professional tool is equipped with sharp blades for cutting the tape. Use it with caution to avoid injuries to your hand. Do not let children use it.

How the TA25 can serve your needs and provide you value

Tabletop dispenser
Limited-run optimal
Customization and Versatility

Discover all the products available in our catalog.

Our catalog

C232 PE Foam

Written by admin on February 23, 2025. Posted in Products.

Foam

The product C232 consists of a 2 mm thick PE foam crosslinked. Thanks to its technical characteristics, the handle offers an extremely comfortable solution for carrying heavy packages.

Specifications

Material: PE Foam

Thickness: 2 mm

Weight: 30 kg/m³

Color: White or colored upon request
Available sizes

150 mm x 350 m: 12/14 rolls/pallet

Other sizes available upon request
Pallet dimensions

Dimensions: 80 x 120 x 170 cm

Weight: 470 to 720 kg

C232 PE Foam Leaflet

Note: The above-mentioned data is based on long-term experience but cannot represent a warranty against eventual damage. Tests should be performed prior to any application.

How the C232 PE Foam can serve your needs and provide you value

Handle Component
Comfortable
Customization and Versatility

Discover all the products available in our catalog.

Our catalog

CC106

Written by admin on February 23, 2025. Posted in Products.

Paper

The product CC106 consists of white or printed paper (up to 6 colors in flexography) used for neutralizing the adhesive tape for carry handle preparation. The application is made by a handle applicator.

Specifications

Backing Type: Paper 78 or 90 g/m² (*)

Weight: 78 or 90 g/m²

Color: White or printed paper up to 6 colors in flexography

(*) Spools = coated paper 78 g/m².
Flat rolls = uncoated paper 90 g/m².

Other dimensions upon request.
Storage

Temperature: 10°C to 40°C

Humidity: 20% to 80% RH

Shelf life: 12 months
Available sizes

25 mm x 3500 m with 6″ core: 1 roll/box, 48 boxes/pallet

25 mm x 750 m with 3″ core: 10 rolls/box, 30 boxes/pallet
Pallet dimensions

Dimensions: 80 x 120 x 170 cm

Weight: 470 to 720 kg

Cartonettes are packed in plasticized packs on disposable pallets, secured with packing straps and covered with stretch film.

CC106 Leaflet

Note: The above-mentioned data are based on long-term experience but cannot represent a warranty against potential damage. It is recommended to conduct preliminary tests before each application.

How the CC106 can serve your needs and provide you value

Handle Component
Long-duration
Customization and Versatility

Discover all the products available in our catalog.

Our catalog

CC104

Written by admin on February 23, 2025. Posted in Products.

Paper

The product CC104 consists of cartonettes for handle formation. These cartonettes provide a sturdy and reliable solution for packaging and transport needs.

Specifications

Weight: 80 g – 300 g

Length: 100 mm – 800 mm

Width: 25 mm – 37.5 mm

Printing: Pantone or four-color process

Cut Center: Precise
Written text

If the printing consists of two words, a 2 mm margin is required on each side.
Storage

Temperature: 10°C to 40°C

Humidity: 20% to 80% RH

Shelf life: 12 months

Packaging

Cartonettes with the following dimensions: 25 x 200 mm

Weight:	210 g 230 g 250 g
Quantity per strip:	210 g: 350 strips 230 g: 300 strips 250 g: 300 strips
Quantity per pack:	10 x 350 10 x 300 10 x 300
Quantity per pallet:	540,000 pieces
Pallet Weight:	470 to 720 kg
Weight Tolerance:	± 5%

Cartonettes are packed in plasticized packs on disposable pallets, secured with packing straps and covered with stretch film.

CC104 Leaflet

Note: The above-mentioned data are based on long-term experience but cannot represent a warranty against potential damage. It is recommended to conduct preliminary tests before each application.

How the CC104 can serve your needs and provide you value

Handle Component
Quick switch
Customization and Versatility

Discover all the products available in our catalog.

Our catalog

C134 S

Written by admin on February 23, 2025. Posted in Products.

Tin sealing

The adhesive tape C134 S has a particular BOPP support. It is used for sealing metal and plastic tins. It offers reliable adhesion and mechanical resistance, ensuring secure and durable sealing for various applications.

Key features

Item: C134 S

Usage: In-line application

Widths: Various sizes available

Adhesive: Hot Melt

Purpose: Sealing metal and plastic tins
Specifications

Backing type: BOPP 40

Thickness: 40 μm

Total thickness: 60 μm

Adhesion on steel: 12 N/25 mm

Tensile strength: 150 N/25 mm

Elongation: 140%

Color: Transparent
Storage

Temperature: 10°C to 40°C

Humidity: 20% to 80% RH

Shelf life: 12 months
Available sizes

mm 12-15-18 x 5000-8000-10000 m/roll: 1 roll/box, 48 boxes/pallet

Other sizes available upon request

Pallet Dimensions: 80 x 120 x 170 cm

Weight: 470 to 720 kg

C134 S Leaflet

C134 S TDS

How the C134 S can serve your needs and provide you value

High-strength Sealing
Package-sealing
Customization and Versatility

Discover all the products available in our catalog.

Our catalog

Temperature:	10°C to 40°C
Humidity:	20% to 80% RH
Shelf life:	12 months

25 mm x 3500 m (with 6″ H 180 core):	1 roll/box, 48 boxes/pallet (about 370 kg)
25 mm x 5000 m (with 6″ H 350 core):	1 roll/box, 24 boxes/pallet (about 500 kg)

mm 25 X 5000-6000 m with 6″ core H 180:	1 roll/box
mm 30 X 5000 m with 6″ core H 180:	1 roll/box
48 boxes/pallet

Item:	TA25
Usage:	Bench dispenser for adhesive tapes
Width:	Up to 50 mm (2″)
Maximum External Diameter:	360 mm
Core Size:	75 mm (3″)

Material:	PE Foam
Thickness:	2 mm
Weight:	30 kg/m³
Color:	White or colored upon request

Backing Type:	Paper 78 or 90 g/m² (*)
Weight:	78 or 90 g/m²
Color:	White or printed paper up to 6 colors in flexography

25 mm x 3500 m with 6″ core:	1 roll/box, 48 boxes/pallet
25 mm x 750 m with 3″ core:	10 rolls/box, 30 boxes/pallet

Weight:	80 g – 300 g
Length:	100 mm – 800 mm
Width:	25 mm – 37.5 mm
Printing:	Pantone or four-color process
Cut Center:	Precise

Backing type:	BOPP 40
Thickness:	40 μm
Total thickness:	60 μm
Adhesion on steel:	12 N/25 mm
Tensile strength:	150 N/25 mm
Elongation:	140%
Color:	Transparent

Item:	C134 S
Usage:	In-line application
Widths:	Various sizes available
Adhesive:	Hot Melt
Purpose:	Sealing metal and plastic tins

Author: admin

How the PP102 can serve your needs and provide you value

Discover all the products available in our catalog.

How the C705 HL LDPE70 can serve your needs and provide you value

Discover all the products available in our catalog.

How the C105 FA – UV can serve your needs and provide you value

Discover all the products available in our catalog.

How the TA25 can serve your needs and provide you value

Discover all the products available in our catalog.

How the C232 PE Foam can serve your needs and provide you value

Discover all the products available in our catalog.

How the CC106 can serve your needs and provide you value

Discover all the products available in our catalog.

How the CC104 can serve your needs and provide you value

Discover all the products available in our catalog.

How the C134 S can serve your needs and provide you value

Discover all the products available in our catalog.

Find your tape

Let’s find together the product that adapts best to your needs.
