The product C232 consists of a 2 mm thick PE foam crosslinked. Thanks to its technical characteristics, the handle offers an extremely comfortable solution for carrying heavy packages.
Specifications
Material:
PE Foam
Thickness:
2 mm
Weight:
30 kg/m3
Color:
White or colored upon request
Available sizes
150 mm x 350 m:
12/14 rolls/pallet
Other sizes available upon request
Pallet dimensions
Dimensions:
80 x 120 x 170 cm
Weight:
470 to 720 kg
C232 PE Foam Leaflet
Note: The above-mentioned data is based on long-term experience but cannot represent a warranty against eventual damage. Tests should be performed prior to any application.
How the C232 PE Foam can serve your needs and provide you value
Handle Component
Comfortable
Customization and Versatility
Discover all the products available in our catalog.
The product CC106 consists of white or printed paper (up to 6 colors in flexography) used for neutralizing the adhesive tape for carry handle preparation. The application is made by a handle applicator.
Specifications
Backing Type:
Paper 78 or 90 g/m2 (*)
Weight:
78 or 90 g/m2
Color:
White or printed paper up to 6 colors in flexography
(*) Spools = coated paper 78 g/m2. Flat rolls = uncoated paper 90 g/m2.
Other dimensions upon request.
Storage
Temperature:
10°C to 40°C
Humidity:
20% to 80% RH
Shelf life:
12 months
Available sizes
25 mm x 3500 m with 6″ core:
1 roll/box, 48 boxes/pallet
25 mm x 750 m with 3″ core:
10 rolls/box, 30 boxes/pallet
Pallet dimensions
Dimensions:
80 x 120 x 170 cm
Weight:
470 to 720 kg
Cartonettes are packed in plasticized packs on disposable pallets, secured with packing straps and covered with stretch film.
CC106 Leaflet
Note: The above-mentioned data are based on long-term experience but cannot represent a warranty against potential damage. It is recommended to conduct preliminary tests before each application.
How the CC106 can serve your needs and provide you value
Handle Component
Long-duration
Customization and Versatility
Discover all the products available in our catalog.
The product CC104 consists of cartonettes for handle formation. These cartonettes provide a sturdy and reliable solution for packaging and transport needs.
Specifications
Weight:
80 g – 300 g
Length:
100 mm – 800 mm
Width:
25 mm – 37.5 mm
Printing:
Pantone or four-color process
Cut Center:
Precise
Written text
If the printing consists of two words, a 2 mm margin is required on each side.
Storage
Temperature:
10°C to 40°C
Humidity:
20% to 80% RH
Shelf life:
12 months
Packaging
Cartonettes with the following dimensions: 25 x 200 mm
Cartonettes are packed in plasticized packs on disposable pallets, secured with packing straps and covered with stretch film.
CC104 Leaflet
Note: The above-mentioned data are based on long-term experience but cannot represent a warranty against potential damage. It is recommended to conduct preliminary tests before each application.
How the CC104 can serve your needs and provide you value
Handle Component
Quick switch
Customization and Versatility
Discover all the products available in our catalog.
The adhesive tape C134 S has a particular BOPP support. It is used for sealing metal and plastic tins. It offers reliable adhesion and mechanical resistance, ensuring secure and durable sealing for various applications.
Key features
Item:
C134 S
Usage:
Metal and plastic box closure, in-line application
Widths:
Various sizes available
Adhesive:
Hot Melt
Purpose:
Sealing metal and plastic tins
Specifications
Backing type:
BOPP 40
Thickness:
40 μm
Total thickness:
60 μm
Adhesion on steel:
12 N/25 mm
Tensile strength:
150 N/25 mm
Elongation:
140%
Color:
Transparent
Storage
Temperature:
10°C to 40°C
Humidity:
20% to 80% RH
Shelf life:
12 months
Available sizes
15 mm x 5000 m:
15 mm x 8000 m:
1 roll/box
1 roll/box
Other sizes available upon request
Pallet Dimensions:
80 x 120 x 170 cm
Weight:
470 to 720 kg
C134 S Leaflet
C134 S TDS
Note: The data provided are reference values taken from production samples and do not constitute a guarantee for the results of the application. Every single application should be tested in advance.
How the C134 S can serve your needs and provide you value
High-strength Sealing
Package-sealing
Customization and Versatility
Discover all the products available in our catalog.
The adhesive tape C705 HL LDPE100 PCR30 consists of a transparent MOPE tape laminated with LDPE insert containing post-consumer recycled (PCR) material. The content of PCR is at least 30% of the plastic. The handle is suitable for recycling together with the shrinkable PE of the bottle pack, making it an environmentally friendly option for packaging needs.
Key features
Item:
C705 HL LDPE100 PCR
Usage:
In-line application
Widths:
Various sizes available
Purpose:
Transport of heavy and bulky packages
Adhesive:
Hot Melt
Specifications
Backing type:
MOPE
Thickness:
54 – 56 μm
Total thickness:
74 – 76 μm
Adhesion on steel:
11 – 15 N/25 mm
Adhesion on PE:
5.0 N/25 mm
Tensile strength:
300 – 350 N/25 mm
Elongation:
40%
Color:
Transparent
Insert:
PE 100 um white with PCR ≥ 30%
Storage
Temperature:
10°C to 40°C
Humidity:
20% to 80% RH
Shelf life:
12 months
Available sizes
25 mm x 330 m (with 6″ H 180 core):
25 mm x 3500 m (with 6″ H 180 core):
12 rolls/box
1 roll/box
25 mm x 5000 m (with 6″ H 350 core):
1 roll/box
Other sizes available upon request
Pallet Dimensions:
80 x 120 x 170 cm
Weight:
470 to 720 kg
C705 HL LDPE100 PCR Leaflet
C705 HL LDPE100 PCR TDS
Note: The data provided are reference values based on long experience in the manufacture of handles and do not constitute a guarantee for the results of the application. Every single application should be tested in advance. We decline any responsibility for direct or indirect damage due to the application of the handle on materials other than shrink PE film.
How the C705 HL LDPE100 PCR30 can serve your needs and provide you value
Sustainability and Environment
Resource-saving
Customization and Versatility
Discover all the products available in our catalog.
The C12550 FA Hot Melt tape shows technical characteristics suitable for adhesive handle preparation for high adhesion or frozen application. The elevated resistance of the PET film against high temperatures permits the use of this adhesive tape in shrink-ovens without deformation or degradation of the product characteristics.
Key features
Item:
C 12550 FA Transparent
Usage:
In-line application
Widths:
Various sizes available
Purpose:
Transport of heavy and bulky packages, up to 20 KG
Adhesive:
Hot Melt
Specifications
Backing type:
PET 50
Thickness:
49 – 51 μm
Total thickness:
79 – 81 μm
Adhesion on steel:
18 N/25 mm
Adhesion on PET:
22 – 30 N/25 mm
Tensile strength:
190 – 210 N/25 mm
Elongation at break:
120 – 150%
Color:
Transparent
Storage
Temperature:
10°C to 40°C
Humidity:
20% to 80% RH
Shelf life:
12 months
Available sizes
25 mm x 5000 m (with 6″ H 180 core):
1 roll/box
25 mm x 6500 m (with 6″ H 180 core):
1 roll/box
Other sizes available upon request
Pallet Dimensions:
80 x 120 x 170 cm
Weight:
470 to 720 kg
C12550 FA Leaflet
C12550 FA TDS
Note: The data provided are reference values based on long experience in the manufacture of handles and do not constitute a guarantee for the results of the application. Every single application should be tested in advance. We decline any responsibility for direct or indirect damage due to the application of the handle on materials other than shrink PE film.
How the C 12550 FA can serve your needs and provide you value
Heat-defying
Strong grip
Customization and Versatility
Discover all the products available in our catalog.
Alimac® Group’s C105 FV – UV Handle Tape is the perfect solution for obtaining adhesive handles for transporting heavy and bulky packages. Thanks to a combination of suitable raw materials, it is particularly resistant to UV radiation. With high adhesion on the shrink PE film, it offers special mechanical resistance and inertia to oxidizing agents. Made of MOPP polypropylene material, it guarantees durability and reliability.
Key features
Item:
C105 FV – UV Transparent
Usage:
In-line application
Widths:
Various sizes available
Purpose:
Transport of heavy and bulky packages, up to 20 KG
Adhesive:
Hot Melt
Material:
MOPP
Higher Thickness:
High Adhesion
UV resistance
Specifications
Backing type:
MOPP
Thickness:
54 – 56 μm
Total thickness:
76 – 78 μm
Adhesion on steel:
11 – 25 N/25 mm
Adhesion on PE:
5.0 N/25 mm
Tensile strength:
380 – 480 N/25 mm
Elongation at break:
24 – 32%
Color:
Transparent
Storage
Temperature:
10°C to 40°C
Humidity:
20% to 80% RH
Shelf life:
12 months
Available sizes
25 mm x 5000/6500 m (with 6″ H 180 core):
1 roll/box
30 mm x 5000 m (with 6″ H 180 core):
1 roll/box
37.5 mm x 3000 m (with 6″ H 180 core):
1 roll/box
48 boxes/pallets
C105 FV – UV Leaflet
C105 FV – UV TDS
Note: The data provided are reference values based on long experience in the manufacture of handles and do not constitute a guarantee for the results of the application. Every single application should be tested in advance. We decline any responsibility for direct or indirect damage due to the application of the handle on materials other than shrink PE film.
How the C105 FV – UV can serve your needs and provide you value
Versatile
Heavy-load / Heavy-carrying
Customization and Versatility
Discover all the products available in our catalog.
Alimac Group’s PoP115 HL Handle Tape is the perfect solution for obtaining adhesive handles for transporting heavy and bulky packages. Made of paper, this tape offers balanced adhesion and special mechanical strength. It is printable in up to 6 colors, both in flexo and offset, to meet all customer needs.
Key features
Item:
PoP115 HL
Usage:
In-line Application
Widths:
Various sizes available
Purpose:
Transport of heavy and bulky packages, up to 20 KG
Adhesive:
Hot Melt
Material:
Paper
Customizable:
Flexo (up to 6 colors) and offset printing
Specifications
Backing type:
Paper
Weight:
115 g/m2
Total weight:
140 g/m2
Adhesion on steel:
12 N/25 mm
Tensile strength:
250 N/25 mm
Elongation:
12%
Color:
Transparent
Storage
Temperature:
10°C to 40°C
Humidity:
20% to 80% RH
Shelf life:
12 months
Available sizes
Depending on handle dimensions
PoP115 HL Leaflet
Note: The data provided are reference values based on long experience in the manufacture of handles and do not constitute a guarantee for the results of the application. Every single application should be tested in advance. We decline any responsibility for direct or indirect damage due to the application of the handle on materials other than shrink PE film.
How the PoP115 HL can serve your needs and provide you value
Plastic-free
Customizable Printing
Durable Paper Material
Discover all the products available in our catalog.
Alimac® Group’s C12550 Handle Tape is the perfect solution for obtaining adhesive handles for transporting heavy and bulky packages. Thanks to its PET composition, it offers special mechanical strength and high adhesion. Made of polyester material, it guarantees durability and reliability. Ideal for in-line applications and pre-shrink use.
Key features
Item:
C12550 HM Transparent
Usage:
In-line application
Widths:
Various sizes available
Purpose:
Transport of heavy and bulky packages, up to 20 KG
Adhesive:
Hot Melt
Material:
Hot melt PET
High Adhesion:
High Temperature Resistant
Specifications
Backing type:
PET
Thickness:
49 – 51 μm
Total thickness:
69 – 71 μm
Adhesion on steel:
11 – 15 N/25 mm
Adhesion on PE:
5.0 N/25 mm
Tensile strength:
190 – 210 N/25 mm
Elongation at break:
120 – 150%
Color:
Transparent
Storage
Temperature:
10°C to 40°C
Humidity:
20% to 80% RH
Shelf life:
12 months
Available sizes
25 mm x 5000 m (with 6″ H 180 core)
1 roll/box
25 mm x 6500 m (with 6″ H 180 core):
1 roll/box
Other sizes available upon request
C12550 Leaflet
C12550 TDS
Note: The data provided are reference values based on long experience in the manufacture of handles and do not constitute a guarantee for the results of the application. Every single application should be tested in advance. We decline any responsibility for direct or indirect damage due to the application of the handle on materials other than shrink PE film.
How the C12550 can serve your needs and provide you value
Heat-defying
Heavy-load / Heavy-carrying
Suitable for in-line applications and pre-shrink use
Discover all the products available in our catalog.
Alimac® Group’s C12050 Handle Tape is the ideal solution for obtaining adhesive handles for transporting heavy and bulky packages. Made of a transparent solvent-based adhesive tape and a transparent PET film, it offers special mechanical strength and high adhesion. The PET material is resistant to high temperatures, allowing the belt to be used in shrink ovens without deformation or degradation of the product characteristics.
Key features
Item:
C12050 Transparent
Usage:
In-line application
Widths:
Various sizes available
Purpose:
Transport of heavy and bulky packages, up to 20 KG
Adhesive:
Solvent
Material:
Solvent PET
High Adhesion:
High Temperature Resistant
Specifications
Backing type:
PET
Thickness:
49 – 51 μm
Total thickness:
67 – 69 μm
Adhesion on steel:
8 – 13 N/25 mm
Adhesion on PE:
3.5 N/25 mm
Tensile strength:
190 – 210 N/25 mm
Elongation at break:
120 – 150%
Color:
Transparent
Storage
Temperature:
10°C to 40°C
Humidity:
20% to 80% RH
Shelf life:
12 months
Available sizes
25 mm x 5000 m (with 6″ H 180 core):
1 roll/box
25 mm x 6500 m (with 6″ H 180 core):
1 roll/box
Other sizes available upon request
C12050 Leaflet
C12050 TDS
Note: The data provided are reference values based on long experience in the manufacture of handles and do not constitute a guarantee for the results of the application. Every single application should be tested in advance. We decline any responsibility for direct or indirect damage due to the application of the handle on materials other than shrink PE film.
How the C12050 can serve your needs and provide you value
Heat-defying
High-strength
Customization and Versatility
